Electrical LT Panel Suppliers in Pune

Types of Electrical LT Panel

We as leading electrical LT panel suppliers in Pune, Maharashtra deliver following types of Power Distribution Panels.

• Power Factor Panel: This is a panel which automatically regulates the power factor of a system by picking or not picking capacitor banks to achieve better electrical economy and lower utility bills.
• Lighting Panel: A special electrical panel used to regulate and shield the circuits serving the lighting systems of a building, usually with inbuilt automated timers or sensors.
• LT Panels: low tension panels are acronym used to describe a type of distribution boards that carry and distribute low voltage (usually below 1,000V) electrical power to serve a building or a facility.
• Power Control Center Panel: This is a primary electrical control panel that gathers and distributes electrical power to different parts or circuits in a large facility.
• Electric power distribution: The last phase of electricity distribution, which entails the network of lines, and equipment that transfer electric power of the transmission system to the individual consumers.
• Fire Panel: The control panel of a fire alarm system that is located centrally and that is used to monitor other sensors, notify occupants of a fire and also activate other safety systems.
• Emergency Control Panels: A control board that operates and controls a system in the event of an emergency, as is the case with an emergency power shut down system or a backup generator control.

Key Specifications of Electrical LT Panel

Below are the technical specifications of Low Tension (LT) Panel Services.

Specification	Details
Voltage Rating	230/400V AC, 3-phase, 50Hz (customizable as per requirement)
Current Rating	10A – 4000A (depending on panel type and load)
Short-Circuit Rating	25kA – 50kA (for 1 second, depending on design)
Insulation Level	1.2 kV (for LV panels)
Protection Devices	MCCBs, MCBs, RCCBs, Fuses, Earth Fault Relays, Overload Relays
Key Components	Bus bars (copper or aluminium), Contactors, Relays, Starters, Meters, PLC/Automation controllers
Enclosure Material	CRCA Sheet / Mild Steel / Powder-coated steel with IP 42 – IP 55 protection (as per requirement)
Mounting Type	Floor-mounted, wall-mounted, or free-standing
Monitoring & Control	Digital or analogue meters for voltage, current, frequency, and power factor; optional remote SCADA integration
Cooling & Ventilation	Natural or forced air ventilation, optional fans for high load panels
Standards Compliance	IEC 61439, IS 8623, IS 7098, IS 3231 (or as per client requirement)
Applications	Industrial plants, commercial buildings, data centres, solar power integration, DG synchronization, and motor control systems

Components of LT Panel:

• Circuit Breakers: Automatic switches used to eliminate over currents and short circuits to the electrical system by interrupting the flow of power.
• Busbars: The business bars that are used as the main distribution path that conducts and supplies higher current to different circuits in the panel, are made up of conductive metal.
• Relays: This is a device that detects faults or abnormal conditions, and activates a circuit breaker to trip so that the system is rapidly fault cleared.
• Meters and Indicators: Voltmeters, ammeters, or similar types of devices that show and indicate the current state of the system and the actual electrical parameters.
• Control Switches: Control switches are used in the control and management of the power supply to certain circuits, and can be of the types of manual switches and push buttons.
• Enclosure: This is the protective metal cabinet that encloses all the internal parts, protecting them against the environment and making them safe.

Benefits of Electrical LT Panel

As electrical LT Panel suppliers in Pune, Here are the benefits of Low-Voltage Distribution Panels.

• Safe Power Distribution: LT panels are used as a junction to control electricity. They avoid hazardous overloads, by spreading power safely to various sections of a building or factory. That is why the whole electrical system becomes more stable and less prone to accidents such as electrical fires.
• Centralized Control: These panels allow operators to monitor and have one location to control several electrical circuits and motors. You can simply monitor all of it in one place rather than having to go to each machine individually and ensure that everything is running smoothly and in-time.
• Equipment Protection: Machinery and equipment are expensive, and safety devices such as breakers and fuses are provided as built-in pedestrian protection. In case of an issue such as short circuit, the panel will automatically disconnect the power to that particular circuit before the connected equipment is destroyed.
• Energy Efficiency: Most LT panels have special units which enhance the power factor of a system. This not only saves energy that goes to waste, but can also save you a lot of money on electricity. It is about utilizing the best you can when using power; it is not buying power that does not work.
• Uninterrupted Power Supply: LT panels can be fitted with technology which will automatically switch off the power supply in the event of faults in the main supply. This helps ensure that key equipment like in hospitals or data centres is operating even during a blackout.

Applications of Electrical LT Panel

As Electrical LT panel suppliers in Maharashtra below are the areas of application of Low-Voltage Distribution Panels.

• Commercial and residential buildings: LT panels supply power to the lighting, air conditioning, lifts and other necessary systems in offices, hotels, malls, and apartments. They provide safe and dependable power circulation in the building.
• Manufacturing & Industry: Electrical Distribution Panel Services provide an uninterrupted power supply to assembly lines, CNC machines and robotic equipment among other heavy machinery to support continuous production in factories and industrial plants.
• Healthcare & Education: LT panels are designed both to provide uninterrupted power to life-support systems in hospitals and to supply power to classrooms, laboratories, and office buildings in schools and universities.
• Data Centres & IT Parks: Electrical Control Breaker Box ensure power reliability and sustained operation of server, networking and IT infrastructure, eliminating downtime and data loss in vital installations.
• Process Industries: LT panels control energy to operate equipment continuously over a period of time in food processing and chemical plants, as well as dairies, mixers, refrigeration units and conveyor systems, among others.

Why to choose us?

• Long-lasting & reliable panels: Our products consist of high-quality LT panels which are meant to last in industrial and commercial use.
• Tailored Power Solutions: We can customize our panels to fit the requirements of factories, offices, hospitals, and data centres.
• Certified Safety and Efficiency: These panels are all of the IS/IEC standard and help reduce the amount of energy wasted thus, making it safe and economical to operate.

Universal Power Tech is significant Electrical LT Panel suppliers in Pune, Maharashtra. The high quality of our LT panels is to provide safety and low voltage power distribution to homes, commercial areas and industrial establishments. They are constructed using sturdy materials and enhanced safety measures to safeguard equipment, reduce downtimes, and ease maintenance. They protect valuable equipment, reduce risks in operations and provide stability in functionality, leading to your place of work operating without unexpected failures. Connect with us for high-performance LT Panels.
